Glentor B80
Drilling machine B80
{acf_typ_stroje_en} B80
Compact power for small projects
- Self-propelled machine
- Front loading
- Drilling, DTH pre-drilling
- Max. 8,000 Nm
- Max. 2.5m screw
01 | Description
The B80 model represents the golden mean among our machines. It offers the ideal combination of performance, stability and flexibility. Thanks to its robust construction on a fixed chassis, it works reliably even in more difficult conditions where greater certainty and safety are needed.
The machine can work with a torque of up to 8,000 Nm at 20 rpm or alternatively 2,000 Nm at 85 rpm, which guarantees enough power for reliable drilling even in harder soil profiles. The maximum length of the ground screw of 2.5 m provides a wide range of applications from small constructions to more demanding foundations of solar structures or wooden buildings.
02 | Specification
| Post Title | Post Date |
|---|---|
torque{acf_specifikace_nazev_en} | 8 000 Nm / 20 rpm 2 000 Nm / 85 rpm{acf_specifikace_hodnota_en} |
pressing force{acf_specifikace_nazev_en} | 12 000 N{acf_specifikace_hodnota_en} |
screw length{acf_specifikace_nazev_en} | 2,5 m{acf_specifikace_hodnota_en} |
weight{acf_specifikace_nazev_en} | 2 480 kg{acf_specifikace_hodnota_en} |
transport dimensions (w × h × d){acf_specifikace_nazev_en} | 980 × 2 100 × 3 500 mm{acf_specifikace_hodnota_en} |
combustion engine{acf_specifikace_nazev_en} | Hatz 3H50TICD{acf_specifikace_hodnota_en} |
performance{acf_specifikace_nazev_en} | 43,7 kW / 2 800 rpm{acf_specifikace_hodnota_en} |
pressure / flow / tank volume{acf_specifikace_nazev_en} | 280 bar / 65 l/min / 100 l{acf_specifikace_hodnota_en} |
travel speed{acf_specifikace_nazev_en} | 3 km/h{acf_specifikace_hodnota_en} |
carriage tilt side/front{acf_specifikace_nazev_en} | ±18°/8°{acf_specifikace_hodnota_en} |
chassis{acf_specifikace_nazev_en} | solid{acf_specifikace_hodnota_en} |
03 | Accessories
Preventer
Preventer
Purge head
Purge head
DTH pilot drilling kit
DTH pilot drilling kit
Tool box
Tool box
Telematics unit
Telematics unit
Screw adapters*
Screw adapters*
